Home / Products / Explosion-proof equipment / Explosion-proof centrifugal Sifter
High output: 5-10 times than other lkind of vibrating screen;
High efficiency: Screening efficiency is up to 95%;
Used in combination: Can be used in conjunction with various grinding machines and wind types;
Cost savings: Low noise, low energy consumption, continuous operation, and reduced maintenance.
Food industry, pharmaceutical industry, chemical industry, metal, metallurgical mining, other industries, etc.
Various powders, etc.
| Model | A(mm) | B(mm) | C(mm) | D(mm) | E(mm) | F(mm) | G(mm) | H(mm) | I(mm) | J(mm) |
| BWSA18-65 | 1405 | 444 | 428 | 1420 | 159 | 219 | 102 | 916 | 850 | 1040 |
| BWSA30-100 | 1867 | 655 | 616 | 1550 | 159 | 219 | 102 | 1040 | 850 | 1040 |
| Model | Screen cage surface area(m2) | Power(kW) | Impeller speed(r/min) | Input air pressure(Mpa) | Input gas volume(m3/min) | Weight(kg) | Motor explosion-proof mark | Control box explosion-proof mark | Screen specifications (mesh/inch) |
| BWSA18-65 | 0.47 | 2.2 | 815-1109 | 0.2 | 0.1-0.2 | 250 | Exd ⅡC T5 Gb/Ex tD A21 IP65 T100℃ | Ex dⅡCT4 Gb/Ex tD A21 IP65 T130℃ | 2-500 |
| BWSA30-100 | 0.85 | 4 | 824-982 | 0.2 | 0.1-0.2 | 420 |
Note 1: The processing capacity takes flour as an example, and the screening mesh is 30 mesh.
Note 2: The substances processed by QLSL200-600 take traditional Chinese medicine preparations as an example, and the screening mesh size is 30 mesh.
A quick-release linear vibrating screen designed and manufactured to meet the high-end requirements of food, pharmaceutical and other industries.
This equipment is suitable for unpacking, placing, screening and unloading small bags of materials in the food, pharmaceutical, chemical and metallurgical industries.
Impurities and foreign matter are separated and discharged to the slag discharge port. The safety officer of the production line
