Scope of application: Fine chemicals, pharmaceutical raw materials, metal powders, abrasives and other industries, as well as oil and gas filtration, flame and explosion protection and other production environments that have special requirements for equipment have unique effects.
Application materials: Chinese medicine powder, API, pharmaceutical intermediates, food additives, molybdenum powder, tungsten powder, nickel powder, cobalt powder, copper powder, lead powder, corundum, emery, alloy powder, welding rod powder, manganese dioxide, electrolytic copper Powder, electromagnetic materials, abrasive powder, quartz sand, silicon carbide, silicon powder, resin powder, zircon powder, silicon powder, various pigments, glazes, powder coatings, etc.
Fine chemicals, pharmaceutical raw materials, metal powders, abrasives and other industries, as well as oil and gas filtration, flame and explosion protection and other production environments that have special requirements for equipment have unique effects.
Chinese medicine powder, API, pharmaceutical intermediates, food additives, molybdenum powder, tungsten powder, nickel powder, cobalt powder, copper powder, lead powder, corundum, emery, alloy powder, welding rod powder, manganese dioxide, electrolytic copper Powder, electromagnetic materials, abrasive powder, quartz sand, silicon carbide, silicon powder, resin powder, zircon powder, silicon powder, various pigments, glazes, powder coatings, etc.
Model | A (mm) | B (mm) | C (mm) | D (mm) | E (mm) | F (mm) | H (mm) | I (mm) | Single layer height(mm) | Double layers height(mm) | Three layers height(mm) |
S49-600 | 530 | 430 | 246 | 600 | 100 | 70 | 391 | 415 | 785 | 910 | 1040 |
S49-800 | 680 | 580 | 246 | 800 | 125 | 80 | 514 | 430 | 855 | 1005 | 1155 |
S49-1000 | 800 | 700 | 246 | 1000 | 150 | 95 | 615 | 430 | 865 | 1015 | 1065 |
S49-1200 | 975 | 855 | 400 | 1200 | 180 | 100 | 717 | 550 | 1020 | 1170 | 1320 |
S49-1500 | 1190 | 1050 | 400 | 1500 | 180 | 116 | 866 | 545 | 1090 | 1270 | 1440 |
S49-1800 | 1580 | 1440 | 400 | 1800 | 200 | 150 | 1070 | 675 | 1230 | 1400 | 1570 |
S49-2000 | 1800 | 1640 | 400 | 2000 | 200 | 190 | 1210 | 685 | 1280 | 1445 | 1615 |
It adopts advanced sealing technology to prevent leakage and extend service life. The sealing gap can be automatically compensated with the use process.
Gaofu combines ultrasonic and vibrating screens to solve the problem of difficult screening of highly adsorbent materials.
It can screen 6 particle sizes, and the sieve body diameter ranges from 600mm (24 inches) to 2600mm (104 inches)
